FIBREGLASS LADDERS

Max. Load 150 kg \| Spacing between rungs 300mm
Item	NO. of steps	A(mm)	B(mm)	C(mm)	Weight(kg)
FO26-102	3	1060	881	484	6.10
FO26-103	4	1337	1078	521	7.50
FO26-104	5	1615	1275	557	8.70
FO26-105	6	1839	1472	595	10.5
FO26-106	7	2170	1669	632	11.6
FO26-107	8	2450	1866	669	13.7
FO26-108	9	2727	2063	706	14.9

Max. Load 150 kg \| Spacing between rungs 300mm
Item No.	Steps	A(mm)	B(mm)	C(mm)	Weight(kg)	Cu Meter	Pack Size	20’	40’	40H	Sku
LCS500GFA1HB	32	4995	8895	400/485	34.7	0.489	511x50x19	52	104	112	0601041014
LCS560GFA1HB	36	5595	9795	400/485	39.5	0.546	564x50x19	52	104	122	0601041015
LCS620GFA1HB	40	6195	10695	400/485	43.5	0.605	624x50x19	0	52	61	0601041016
LCS680GFA1HB	44	6795	11895	400/485	49.5	0.686	686x50x20	0	48	57	0601041017

Max. Load 150 kg \| Spacing between rungs 280mm
Item No.	Steps	A(mm)	B(mm)	C(mm)	Weight(kg)
FG21-105	6	1560	1065	510	7.8
FG21-107	8	2100	1390	575	9.8

Max. Load 150 kg \| Spacing between rungs 280mm
Item No.	Steps	A(mm)	B(mm)	C(mm)	Weight(kg)
ALU21-105	6	1560	1065	510	5
ALU21-107	8	2100	1390	575	6 . 2
